i1320 Scanner

{2jtab:Overview}

A powerful combination of performance and value, for all your departmental scanning needs

Letā€™s get right to itā€”the KODAK i1320 Plus Scanner delivers the highest level of capability and affordability of any product in their category. This is true breakout performance, with ease of use, versatility and image quality that sets a new benchmark.

Flexibility to meet wide-ranging needs

You can auto-feed virtually any document, from the size of a driverā€™s license up to 863 mm (34 in.) longā€” at speeds up to 60 pages per minute. Scan both sides of documents in a single pass and output images in color, bitonal or grayscale.

Our Smart Touch feature allows you to easily select the right scan settings and applications for the job. At the touch of a button, scan documents to:

• Microsoft SharePoint
• File
• E-mail
• Printers
• Other desktop applications that support TIFF, JPEG, RTF, BMP, PDF and searchable PDF output

In addition, the i1320 Plus Scanner has a unique tilt-and-scan feature that allows you to easily select the best scanning position for your job:

• Flat with trays extended for higher-volume batch scanning
• Fully upright with the input tray folded down for ad hoc and transaction feeding (your scanner can even be positioned up against a wall and still auto-feed documents)

There are also optional ā€œtetheredā€ flatbed accessories in A3 and A4 sizes for more convenience and flexibility. Just connect either, and you can scan A3 exception documents at up to 600 dpi and A4 exception documents at up to 1,200 dpi optical resolution. Then just unplug and store the flatbed. Itā€™s that easy!

Enjoy sharp image quality

The i1320 Plus model features 600 dpi optical resolution and enhanced Perfect Page Image Processing, a Kodak exclusive. This gives you images of exceptional qualityā€”about as automatically as it gets. No need for rescans!

Finally, you can get high performance, ease of use and value at an affordable price point

When you combine our image quality, ease of use and overall performance with the peace of mind that comes with KODAK Service & Support, the i1320 Plus delivers truly awesome value.

{2jtab:Perfect Page Features}

Perfect Page Scanning is a suite of image processing technologies that maximizes the quality of digital images.

And itā€˜s only available in Kodak scanners.

Even when your document is less than perfect, Perfect Page corrects for color, brightness, contrast, readability, orientation and background so your scanned images may actually look better than the original.

The following one-page Perfect Page Matrix shows which imaging features are available in each Kodak scanner.

{2jtab:Specifications}

Scanning Technology

• Dual CCD

Recommended Daily Volume

• Up to 5,000 pages per day

Throughput Speeds (Portrait, letter size)

• Bitonal/grayscale: Up to 60 pages per minute/120 images per minute at 200 dpi
• Color: Up to 40 pages per minute/80 images per minute at 200 dpi

  (Throughput speeds may vary depending on your choice of driver, application software, operating system and PC.)

Optical resolution

• 600 dpi (1200 dpi A4 flatbed accessory)

Output Resolution

• 75, 100, 150, 200, 240, 300, 400, 600 and 1200 dpi

Max./Min. Document Size

• 215 mm x 863 mm (8.5 in. x 34 in.)/50 mm x 63.5 mm (2 in. x 2.5 in.)

Paper Thickness and Weight

• 34-413 g/mĀ² (9-110 lb.) paper; ID card thickness: up to 1.25 mm (0.05 in.)

Reliable and Unique Transport

Feeder

• Up toĀ 75 sheets of 75 g/mĀ² (20 lb.) paper
• Handles small documents, such as ID cards, embossed cards and insurance cards

Multi-feed Detection

• With ultrasonic technology

Connectivity

• USB 2.0 (cable included)

Bundled Software

• TWAIN, ISIS, WIA Drivers; KODAK Capture Desktop Software, Smart Touch; Nuance ScanSoft PaperPort and OmniPage. Linux SANE and TWAIN Drivers available from www.kodak.com/go/scanonlinux

Imaging Features

• Perfect Page Scanning; iThresholding; adaptive threshold processing; deskew; autocrop; relative cropping; aggressive cropping; electronic color dropout; dual stream scanning; interactive color, brightness and contrast adjustment; auto orientation; automatic color detection; background color smoothing, image edge fill, image merge, content based blank page detection

File Format Outputs

• Single and multi-page TIFF, JPEG, RTF, BMP, PDF, searchable PDF

Accessories

• KODAK white imaging background accessory (front)
• KODAK A3 Flatbed (black background) Accessory with 1.8-meter (6 ft.) cable
• KODAK A4 Flatbed (white background) Accessory with 1.8-meter (6 ft.) cable
• Optional A4 flatbed black imaging background accessory

Environmental Factors

• Energy Star qualified scanners

Dimensions

• Weight: 5.5 kg (12.0 lbs.)
• Depth:162 mm (6.3 in.) not including input tray and output tray
• Width: 330 mm (13.0 in.)
• Height: 246 mm (9.7 in.) not including input tray
